• 2022 SPRINTER 170 4X4

"ODYSSEY"

2022 Mercedes-Benz Sprinter 2500 4x4  ·  170" Wheelbase  ·  High Roof

27,000 miles   ·   $215,000   ·   San Diego, CA

The original one-off build by Lucas Ravizza the van that launched Ravizza Luxury Vans. Featured in autoevolution and TechEBlog . Inspected by RVIA inspector in 2025. Clean title. 2024    Components carrying this mark were installed by Expedition Off Grid Corporation in December 2024. All such work carries a 3-year labor warranty. Receipts available to the buyer.

1.  Factory Chassis

VIN - On request for serious buyers

Year / Make / Model: 2022 Mercedes-Benz Sprinter 2500

Platform: 907 (VS30 generation)

Body class: Cargo Van high roof

Engine: OM642 3.0L V6 turbodiesel

Output: 188 hp @ 3,800 rpm  ·  325 lb-ft @ 1,400 rpm

Engine management: PedalBox Pro throttle controller + DTE Systems PowerControl X tuner  2024

Transmission: 7G-TRONIC PLUS 7-speed automatic

Drivetrain: 4WD / 4x4

Wheelbase: 170 in

GVWR: 9,050 lb (NHTSA Class 2H)

Payload, bare van: 3,781 lb  (see Weights, §10)

Max towing: 5,000 lb

Brakes: 4-wheel hydraulic disc, ABS

Airbags: Driver + passenger front; thorax-pelvis side; window curtain

TPMS: Direct

Length / Width: 274.3 in / 79.5 in excl. mirrors

Factory roof height: 107.3 in  (increased by rack + tent see §10)

Turning circle: 47.2 ft

Assembly plant: Charleston, South Carolina, USA

Manufacturer: Mercedes-Benz AG

On the engine. This van carries the 3.0L V6 OM642 the high-output option, not the 2.0L four-cylinder. Mercedes has since dropped the V6 from the Sprinter line entirely; current Sprinters are four-cylinder only. The PedalBox and DTE tuner sharpen throttle response and add power on top of the factory output.

2.  Electrical System

House battery: 14.5 kWh self-heating lithium (~1,200 Ah @ 12V)

Cold-weather rating: Discharges to -30°F  ·  recharges to -40°F

Real-world capability: Runs the 10,000 BTU A/C approx. 30 hours on a full charge

Second alternator: Nations 3-belt 280A kit, VS30-specific, with locking flywheel  2024

Regulator: Wakespeed WS500, supply lines run to house bank with shunt voltage monitoring  2024

Solar: 520W tiltable array (roof-tent mounted)

Inverter: Onboard, hard-wired

Monitoring: Victron SmartShunt 500A/50mV

Battery protection: Victron Smart Battery Protect 220A  2024

Distribution: Blue Sea 285-series 120A breaker  ·  Blue Sea 10-gang 150A busbar  ·  300A MEGA fuse  2024

Switching: Dual Garmin PowerSwitch Bluetooth 6-gang boxes (120A each), front and rear, app-controlled, behind custom walnut faceplates  2024

Wiring: ANCOR marine-grade throughout (4/0, 4 AWG, 8 AWG), IP69 waterproof glands  2024

Master cutoff: Stainless discharge-deactivation button (recharge stays live)

Convenience: Countertop wireless charger, multiple 120V outlets and USB

Three independent charging paths 280A alternator, 520W solar, shore.

3.  Climate Four-Season

Primary heat: Rixen's hydronic system

Heat distribution: Radiant floor heat + three hot-air vents

Hot water: Endless on-demand via UL-listed double-wall heat exchanger

Engine integration: Engine-tap heat exchanger; engine and cabin coolant loops kept separate

Remote control: GPS-enabled Rixen's interface

Air conditioning: Cruise N Comfort 12V, 10,000 BTU battery-powered, runs off-grid

Ventilation: Roof fan

Four-season capability: heated floors and self-heating batteries mean the van stays habitable and the power system functional well below freezing, which is where most conversions stop.

4.  Water & Bath

Fresh water: 42 gal

Grey water: 20 gal, electric ball-valve dump

Drinking water: 3-stage filtration

Interior shower: Full pass-through to front cab; modern Italian tile, high-gloss black acrylic

Outdoor shower: Scandvik, Moen Nebia head (1.5 GPM)

Toilet: Laveo Dry Flush no black tank, no composting maintenance

Hot water: On-demand, unlimited (hydronic)

5.  Fuel, Air & Recovery

Fuel tank: S&B 47-gallon extended tank, replacing the factory 24.5-gallon tank. Professionally installed including A/C system remounting to clear the tank nearly double factory range between fills.  2024

Onboard air: ARB twin 12V compressor on a Van Compass engine-bay bracket, 3-gallon expansion tank, 100 PSI automatic pressure switch, 50' airline, dual quick-couplers and Y-splitters  2024

Recovery winch: Warn 12-S Platinum with Factor 55 Hawse 1.5" fairlead and UltraHook rope guard; installed with bumper drop  2024

Tow rating: 5,000 lb, factory hitch

Air-down for sand and rock, air back up at the trailhead without a portable compressor; recover the van, or someone else's, without waiting for a tow.

6.  Kitchen

Cooktop: Induction

Oven: Microwave oven

Refrigeration: 12V compressor fridge

Sink: Undermount, matte black fixtures

Countertops: Fenix matte laminate self-healing, fingerprint-resistant

Coffee station: Concealed behind French-door cabinet

Dining: Convertible table on a custom walnut mount  2024

Provisioned Glassware, dishware, custom silverware organizer

7.  Sleeping & Living Sleeps 6

Primary bed: Electric lift bed, 6'9" side-to-side, sits flush with backrests when lowered

Second bed: Lounge conversion

Third sleeping: Roofnest Falcon 2 rooftop tent + capsules adding 12" of length

Belted seats: 2

Entertainment: Projector and screen

Driver aids: Backup camera

Security: Blink camera system, hard-wired, with marine USB-C outlet  2024

Remote operation: Mid City Engineering remote start with high idle and Drone LTE app control start, pre-heat or pre-cool the van from a phone  2024

Pet monitoring: WAG system (subscription-based)

8.  Interior Craftsmanship

Hand-laid walnut chevron flooring with an inlaid gold separator strip, built by Lucas Ravizza

Roman clay wall finish

Grain-matched solid hardwood drawer faces with custom brass hardware

Smart-tint electric switchable glass closet doors and the four-level pantry go from clear to opaque at a touch

Walnut slat ceiling with integrated linear LED lighting

Custom walnut faceplates fabricated for the Garmin control panels, and a custom walnut table mount

9.  Storage, Suspension & Exterior

Storage

Full standing wet garage skis, snowboards, surfboards, wetsuits

Full-width rear pull-out gear tray on 250-lb drawer slides

Backwoods lockable exterior box  ·  bike rack  ·  leveling jacks

Suspension, Wheels & Tires

Agile Off Road RIP kit suspension

Black Rhino Arsenal wheels

33" BFGoodrich KO2 all-terrain tires

Exterior, Lighting & Access

Awning: Fiamma F45s Eagle 13'9" motorized legless awning in black, with LED light kit  2024

Auxiliary lighting: Baja Designs S1 Sport (x2) and S2 Sport work/scene LEDs with wiring harnesses  2024

Forward lighting: Bull bar with 50" light bar, 4 pod lights, KC ditch lights

Rear doors: Canyon Adventure Vans door stays, 180° hold-open, floor trim modified for bracket clearance  2024

Armor & access: Backwoods front bumper and side ladder

Entry: Amp Research electric running boards, both sides

Racks: Owl tire/ladder combo  ·  Owl Sherpa roof rack
